APC 2.2KVA UPS (BVX2200LI-IN)
694.00
The APC Easy UPS BVX 2200VA offers 230V output with AVR. It has a rated power of 1200W and a battery power of 157VAh. The UPS includes 5 India 3-pin 6A outlets and a lead-acid battery with a recharge time of 6 hours. It includes a user manual for easy installation.
Shipping calculated at checkout.
Specification
Overview
Lead Time: Usually in Stock
Product Type: Uninterruptible Power Supply (UPS)
Product Range: Easy UPS
Performance
Run Time for Load: 1200 W
Load Range: 120 – 1200 W
Run Time Duration: 0 min 22 sec
Max Capacity Used: 100%
Rated Power: 1200 W / 2200 VA
Input
Main Input Voltage: 230 V AC (1 phase)
Input Voltage Range: 140 – 300 V
Network Frequency: 40 – 70 Hz ±5% (auto-sensing)
Plug Standard: India 3-pin 16A
Input Protection: Circuit breaker
Output
Main Output Voltage: 230 V AC (1 phase)
Rated Output: 1200 W / 2200 VA
Output Frequency: 50/60 Hz ±1 Hz
UPS Type: Line Interactive
Waveform: Stepped approximation to sinewave
Transfer Time: 6 ms typical / 10 ms max
Output Connections: 5 × India 3-pin 6A
Battery & Runtime
Battery Type: Lead-acid (internal)
Battery Voltage: 24 V
Battery Capacity: 9 Ah
Recharge Time: 6 hours
Extended Runtime: Not supported
Communication & Protection
Control Panel: LED indicators (Online, Battery, Replace Battery, Overload)
Alarm: On battery, low battery & overload alarms
Surge Energy Rating: 255 J
USB Compatible: No
Physical
Colour: Black
Dimensions: 190 × 140 × 390 mm
Net Weight: 12.2 kg
Mounting Mode: Desktop (Not rack-mountable)
Environmental
Operating Temperature: 0 – 40 °C
Storage Temperature: -20 – 50 °C
Relative Humidity: 0 – 95% non-condensing
Operating Altitude: 0 – 3000 m
Acoustic Noise: 40 dBA
IP Rating: IP20
Certifications: BIS
Packaging & Warranty
Package Type: PCE
Units per Package: 1
Package Dimensions: 29.7 × 49.5 × 23.5 cm
Package Weight: 13.2 kg
Warranty: 24 months UPS / 12 months Battery
The APC Easy UPS BVX 2200VA offers 230V output with AVR. It has a rated power of 1200W and a battery power of 157VAh. The UPS includes 5 India 3-pin 6A outlets and a lead-acid battery with a recharge time of 6 hours. It includes a user manual for easy installation.
